Wilson Dual Band Panel Antenna (301135)

Award winning engineering MADE IN U.S.A

Wilson Electronics Dual Band Panel Antenna (301135)

Benefits & Features

Dropped calls? Boost and increase your cell phone reception with the : Wilson Electronics Dual Band Panel Antenna (301135) ! Conveniently mount this wall panel antenna projecting towards the room/rooms of your choice to broadcast your cell phone signals..

It's designed to be connected with various Wilson Wireless Amplifiers (50 ohms) / SOHO / In-Building / Mobile. For users who prefer a strong one way directional projection of their signals across a hallway into another room, this would be the ideal choice over a dome antenna. If you choose not to utilize this with a repeater, mount it on a window towards the direction of cell towers (whereever you pick up the best signals).

System Applications [ OFFICE - HOME - CORPORATE - SKYSCRAPER - ETC - COVERS UP TO X AMOUNT FT² ]

• Directional antenna
• Built-In ground plane
• Mounting hardware included
• Designed for fixed (building amplifier) installations
• Combines Cellular, SMR (iDEN) and PCS1900 frequencies into one indoor antenna


• Provides a cost-effective solution for high volume deployments and multiple in-building systems
• Unobtrusive - low profile blends easily with internal environment for unobtrusive appearance
• Convenient and simple to install
• Connector - N/Female, requires the following cables for appropriate connections:
  • Directly to Amplifier or Splitter: Use Wilson-400 (952300) Series Extension Cables
    • (Cables are sold separately)


• Color - white
• Model #: 301135 (previously 301122)

Reference [ CELL SIGNAL CALCULATOR ] & [ FAQ - A.G. AMPLIFIER'S GUIDE ]

A BRIEF INTRODUCTION

Package includes

• 1 x Panel Mount Antenna (301135)
• All mounting hardware
• Installation Guide


• Additional notes

  • This antenna requires signal boosters for maximum performance
  • Call us at 1-866-433-5793 to find the best solution & pricing
  • SignalBoost Desktop Series requires the 301155


General specifications

• Part Number: 301135
• Frequency: 806-894 MHz / 1850-1990 MHz
• Impedance: 50 ohms
• Polarization: Vertical
• Antenna Gain: 7-10 dBi Gain
• Max Power: 25 watts
• VSWR: 1.:1
• Connector: N-Female
• Dimensions: 9.8 x 8.7 x 2.4 in
• Built-In Ground Plane

Wilson Electronics Dual Band Panel Mount Antenna (301135)

TIDFV

Disclaimer:

Cell phone signal boosters only work in situations where there are traces of signals. Systems will not work if zero signals can be picked up.

Accessorygeeks.com is not responsible for loss or damages caused by delays in delivery from natural disasters, manufacturer delays, acts of war or other causes beyond our control.

Order the Wilson Dual Band Panel Antenna (301135) today! Don't miss out on this great deal with Free Shipping. The Wilson Dual Band Panel Antenna (301135) is ready to be shipped within 24-48 hours.

Let the Geeks Experts help you with any questions or concerns. Call us today at 1-866-433-5793 or email us at CS@AccessoryGeeks.com.

Buy the Wilson Dual Band Panel Antenna (301135) today at AccessoryGeeks.com
