Detailed Description
The Wilson Cellular PCS Band Yagi Antenna's main benefit over our other
antennas is its ability to focus its signal in one direction. This antenna is
designed for use on stationary objects such as buildings. If this antenna is not
aimed correctly it will lose its effectiveness.
The 17" boom is the main part of the antenna and includes 9 elements
constructed of a single piece of 2mm (14 gauge) aluminum. The Wind Surface Area
is less than 19 square inches. The design of the antenna exposes a small profile
to wind and ice.
The output coaxial connector is an N-Female type and the feed systems is a
"T-Match" which provides low signal loss and wide bandwidth. The
antenna's impedance is 50 ohm with a maximum power rating of 25W.
Pipe mount hardware is included. The pipe mount is adjustable to accommodate
pipes with and outside diameter up to 2".
Since the Yagi is a single band 1850MHz-1990MHz PCS antenna it will only work
with Sprint PCS, T-Mobile or other carriers in PCS markets. It is not compatible
with 800MHz/850MHz Cellular or Nextel/iDEN.
Usage
The Wilson Yagi PCS Cellular Antennas main benefit over our
other antennas is its ability to focus its signal in one direction. This
antenna is designed for use on stationary objects such as buildings. If
this antenna is not aimed correctly it will loose its effectiveness.
PACKAGE CONTENTS:
Yagi Antenna (The Wilson Yagi PCS Cellular Antenna
DOES
NOT Include cables. )
For a short run of 20', you can use our 20' RG-58
Coax extension
For a longer run, Accessorygeeks suggest using one of our
Ultra low loss Cables.
SPECIFICATIONS:
|
Specifications
|
| Part Number |
301124 |
| Frequency Range |
1850MHz-1990Mhz |
| Impedance |
50 Ohms |
| Antenna Gain |
13dBi |
| Maximum Power |
25 Watts |
| Radiation |
Directional |
| Polarization |
Linear, Vertical |
| VSWR |
< 1.7 |
Horizontal
Beam width (3dB) |
40 degrees |
Vertical
Beam width (3dB) |
36 degrees |
| Ground Plane |
Built-In Ground Plane |
| Elements |
9 |
| Connector |
N Female |
| Material |
Aluminum |
| Width |
17" |
| Wind Surface Area |
< 19 sq in |
| Mount |
Pipe, max OD 2" |
FEATURES:
-
Compatible with all 1850-1990MHz PCS Frequency bands
-
Built-in ground plane
-
Directional antenna
-
Pole mounting hardware included (does not include pole)
-
For fixed installations
REQUIRES:
* A
phone
adapter cable is required.
SUPPORTING DOCUMENTS:
Technical Support
Help may be obtained by contacting Wilson Electronics, Inc. at
1-866-294-1660 or tech@wilsonelectronics.com
Monday through Friday between 7:00AM - 3:30PM Pacific Time.
*Due to item size please allow extra time for delivery.
